HPP51330LFP-AOLV(51.2V330Ah 11KwInverter) All In Solar Power Low Voltage Battery
Lithium-ion Battery All In Solar Power Low Voltage Battery
Type: LiFePO4 Battery
Cathode Material: LFP
Minimum Order Quantity: 50
Delivery Time: 20 days
Customization/OEM/ODM: Yes
Factory: HPP
Delivery Method: FOB, EXW, CIF
Payment Method: T/T, L/C, PayPal
Shipping Methods: 10 feet, 20 feet, 40 feet, 60 feet
Solar energy, a renewable and abundant resource, has great potential to reduce our dependence on non-renewable energy sources. Photovoltaic (PV) panels capture sunlight and convert it into electricity. However, the electricity from PV panels is direct current (DC), while homes and industries mainly use alternating current (AC). This is where inverters play a crucial role. HPP51330LFP-AOLV(51.2V330Ah 11KwInverter),All-in solar power low-voltage battery systems typically integrate various technologies to store and manage energy in one unit. They store electricity generated from renewable sources or during periods of low energy demand, and release it when demand is high or renewable energy is insufficient.
General Feature
- Longer cycle life: The cycle life of the battery pack can reach 6000 times, which is 5 times that of the lead-acid battery, effectively saving the replacement and maintenance cost.
- Lighter weight: High energy density, 40% weight of the lead-acid battery.
- Wider temperature range: -20℃~60℃.
- Bluetooth Connection
- Short Circuit Protection
- Temperature Protection
- Charging Overvoltage Protection
- Discharge Undervoltage Protection
- OC/OD Protection
Application
- Solar/Wind Energy Storage System
- Communication Equipment
- Emergency Power System
- Medical Equipment
- UPS Backup Power
- Electric Vehicles/electric mobility
- Fire And Security System
- Lighting
| Characteristic | Specification |
|---|---|
| Battery Capacity | 16.896KWh |
| Rated Power | 11000W / Peak 22000VA |
| Cycle Life | 6000+ times |
| Cell Type | LiFePO4 (3.2V330Ah 16S1P) |
| AC Input | 195-253VAC±3V |
| AC Output | 220/230/240VAC+5% |
| Rated Battery Input Voltage | DC48V |
| PV Input Power | 5500W * 2 channels MAX |
| MPPT Voltage Range | 90-500DC |
| Maximum MPPT Input Voltage | 500VDC MAX |
| AC input current | 150A MAX |
| DC Output | DC:12V 3A; USB:5V 2.4A; TYPE-C:5V 2.4A |
| Overall Dimensions | L780*W260*H950mm |
| Net Weight | 145kg |
| Supported Functions | WIFI (optional), LCD display |
