HPP51280LFP-FRLV512V280Ah Floor Removable Low Voltage Battery (FRLV Series)

Lithium-ion Battery Floor Removable Low Voltage Battery

Type: LiFePO4 Battery
Cathode Material: LFP
Minimum Order Quantity: 50
Delivery Time: 20 days
Customization/OEM/ODM: Yes
Factory: HPP
Delivery Method: FOB, EXW, CIF
Payment Method: T/T, L/C, PayPal
Shipping Methods: 10 feet, 20 feet, 40 feet, 60 feet

HPP batteries are made with really good Grade A+ LiFePO4 cells. This gives them great safety and performance. When we add a smart Battery Management System (BMS), it keeps a close eye on and balances each cell all the time. That means you get the best protection for whatever you use the batteries in.These batteries have all the safety features you need: protection against short circuits, overcharging, over-discharging, overvoltage, and overcurrent. The circuit is designed to be well-balanced for extra safety. The tough build stops things like explosions or fires, even in really tough conditions.

General Feature
  • Supports parallel expansion up to 16 parallel.
  • Compatible with many mainstream inverter brands in the market.
  • Built-in BMS system for battery life protection.
  • Excellent safety: Lithium iron phosphate chemistry eliminates the risk of explosion or combustion.
  • Wider temperature range: -20℃~60℃.
  • Bluetooth Connection
  • Short Circuit Protection
  • Temperature Protection
  • Charging Overvoltage Protection
  • Discharge Undervoltage Protection
  • OC/OD Protection
Product Description

The HPP 51.2V solar battery built with EVE’s A+ grade LiFePO4 cells, offering over 6,000 cycles and a lifespan of 15 years. Up to 32 identical 3.84kWh batteries can be connected in parallel, expanding the capacity range from 7.68kWh, designed for both residential and commercial/industrial users. One of the key features of this product is its versatility in handling varying levels of humidity, with a range from 10% to 90%. This makes it suitable for a wide range of climates and environmental conditions, providing reliable performance regardless of the weather.The built-in BMS prevents overheating, overcharging, and over-discharging. This is a smart, efficient, and durable lithium solar battery solution.

CharacteristicSpecification
Available electricity14.336Kwh
Rated capacity280Ah
Cell configuration16S1P
BMS configuration16S150A
Rated voltage51.2V
Operating voltage range44.8V-58.4V
Rated charging and discharge current75A
Peak current150A Continue@155A 10s
Rated charging and discharging power3.84Kw
Peak power7.68Kw Continue@7.94Kw 10s
Cycle life≥6000 Cycle 80% DOD @25℃
Communication modeCAN,RS485
Parallel numberRecommend 6 in parallel(Maximum support 16 in parallel)
Remote dataBluetooth optional/Wifi
Weight115Kg
Dimensions (L*W*H) mm875*500*270mm
Operating temperatureCharging: 0℃-50℃ / Discharge: -10℃-+60℃
Relative humidity0-95%
Storage temperature<3 Months -10℃-25℃ / <1 Year 0℃-25℃
Maximum working altitude2000m
Class of protectionIP21
Supports inverter communication brandsSMA,Growatt,TBB,Deye,GOODWE,PYLON,Luxpowertek/

Victon energy,SOFAR,INVT
Installation modeWall mounting
Power cable outlet modeUnder
Standards and certificationTransport UN38.3
