25.6V 100/200/300AH Home Solar Battery 2.56/5.12/7.83KWh LIFEPO4 Batteries
Lithium-ion Battery Residential Energy Storage System
Type: LiFePO4 Battery
Cathode Material: LFP
Minimum Order Quantity: 50
Delivery Time: 20 days
Customization/OEM/ODM: Yes
Factory: AOGE POWER
Delivery Method: FOB, EXW, CIF
Payment Method: T/T, L/C, PayPal
Shipping Methods: 10 feet, 20 feet, 40 feet, 60 feet
AOGE POWER batteries are made with really good Grade A+ LiFePO4 cells. This gives them great safety and performance. When we add a smart Battery Management System (BMS), it keeps a close eye on and balances each cell all the time. That means you get the best protection for whatever you use the batteries in.These batteries have all the safety features you need: protection against short circuits, overcharging, over-discharging, overvoltage, and overcurrent. The circuit is designed to be well-balanced for extra safety. The tough build stops things like explosions or fires, even in really tough conditions.
Key Features & Benefits
Long-Lasting Battery Life and a Solid Warranty :They can go through over 6,000 charge cycles, so you can count on them for a long time. And with a strong 5-year warranty, you don’t have to worry about replacing them often.
Monitoring & Protection Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit
Communication : RS485 / RS232 / CAN-bus
Optional Functions :Bluetooth / WiFi / 4G / 5G / Circuit Breaker / Heating / Active Balance / LED Touch Screen / APP
Accessories : Inverter Power Cable, Parallel Cable, Communication Cable, Grounding Wire
Compatible Inverters :Victron / GOODWE / Solis / Growatt / SMA / SAJ / Luxpower / SRNE / Deye / Voltronic, etc.
Product Description
The AOGE POWER 25.6V solar battery built with EVE’s A+ grade LiFePO4 cells, offering over 6,000 cycles and a lifespan of 15 years. Up to 32 identical 5.12kWh batteries can be connected in parallel, expanding the capacity range from 5.12kWh to 163.84kWh, designed for both residential and commercial/industrial users. One of the key features of this product is its versatility in handling varying levels of humidity, with a range from 10% to 90%. This makes it suitable for a wide range of climates and environmental conditions, providing reliable performance regardless of the weather.The built-in BMS prevents overheating, overcharging, and over-discharging. This is a smart, efficient, and durable lithium solar battery solution.
| Model | AG25100LFP-FRLV | AG25200LFP-FRLV | AG25306LFP-FRLV |
| Cell Format | LFP3.2V100AH/8S1P | LFP3.2V200AH/8S1P | LFP3.2V306AH/8S1P |
| Rated Voltage | 25.6V | ||
| Rated Capacity | 100Ah | 200Ah | 306Ah |
| Rated Energy | 2.56KWh | 5.12KWh | 7.83KWh |
| Charge Voltage | 28.4-29.2V | ||
| RCMD Charge Current | 25A | 50A | 50A |
| Max Charge Current | 50A | 100A | 150A |
| Discharge Cut-off Volt. | 21.6V | ||
| Max Discharge Current | 50A | 100A | 150A |
| Dimension (L*W*H) | 435*385*145MM | 650*385*145MM | 650*450*200MM |
| Weight(APPROX.)KG±5% | 25kg | 45kg | 65kg |
| Charge Temperature | 0℃to 55℃ | ||
| Operate Temperature | -10℃to 60℃ | ||
| Storage Temperature | 0℃to 40℃ | ||
| Environmental | <95%RH | ||
| Protection Rating | IP20 | ||
| Cycle Life | 8000Cycle@25℃,60%DOD,0.2C | ||
| 6000Cycle@25℃,80%DOD,0.2C | |||
| Scalability | Max 16 parallel | ||
| Design life/Warranty | 10 years / 5 years | ||
| Cell | IEC62619/UL1642 | ||
| Battery Pack | UN38.3/CE/IEC62619/IEC61000 | ||
| Display | SOC status indicator,LED indicator | ||
| Communication | CAN/RS485/RS232 | ||
| Optional Functions | bluetooth/wifi/lcd/circuit breaker | ||
| Compatible inverter | victron/sol-ark/SMA/GOODWE/SOLIS/SAJ/GROWATT/SRNE/VOLTRONIC/DEYE/ETC. | ||
